Technical Details



Size Range 50 - 200 nm
Channels 4
Standard Channel Sizes 50 nm, 100 nm, 150 nm, 200 nm
Flow Rate 100 ml/min
Sample Volume 5.0 mL/min
Zero Count Level ≤ 20 count/L
Laser Source Solid-state laser
Calibration NIST Traceable
Communication Modes Ethernet, Serial RS-485, 4-20mA
Display TFT Color Touch Screen
Concentration Limit 10,000 counts/mL @ 10% coincidence loss
Enclosure 316L stainless steel
Sample Inlet/Outlet Connection 1/4" Flaretek™
Environmental Conditions Operating 50°F to 104°F (10°C to 40°C), 20% to 95% non-condensing
Environmental Conditions Storage 14°F to 122°F (-10°C to 50°C), up to 98% non-condensing
Sample Temperature 50°F to 122°F (10°C to 50°C)
Sample Pressure 20 PSI to 72 PSI (138 kPa to 496 kPa)
Wetted Surface Materials Quartz, PFA, Kalrez, PTFE
Communication Protocol MODBUS TCP, MODBUS Serial, 4-20mA
Power External Supply: Rated input 120-240V AC 50/60Hz, 0.7A - 1.4A. Rated Output: 24V DC, 5A
Dimensions 9.0”(w) x 13.4”(d) x 8.4”(h) [22.9 x 34.0 x 21.3 cm]
Weight 13.5 lbs (6.1 kg)


Included 24V power adapter, power cord (US/UK/EU/CN), 1.8m USB-RS485 serial cable with industrial connector, 25’ ethernet cable with industrial connector, USB
flash drive with Operators Manual, 2 x 10-foot sample inlet and outlet tubes (with flared tips and lock nuts), flow cell cleaning kit, calibration certificate
and carrying case.
Optional Printed operating manual; additional tubing, additional serial or ethernet cables with industrial connector, flow cell cleaning kit.

Get a Quote


First Name (*)
Last Name (*)
Company Name (*)
Email (*)
Phone (*)
Address (*)
Country (*)
Primary Industry (*)
Message (*)
(*) Required Fields
Click to view 360°

Where Gamma Immunity and Sensitivity Meet


Where Gamma Immunity and Sensitivity Meet

The Vertex50 is the smallest and lightest 50nm liquid particle counter on the market. The Vertex50 has the lowest zero count levels, has integrated manual flow control and incorporates TFT Touch Screen to simplify the user interface and offer an improved local user experience. Based on state-of-the-art technology, it is backed by a two-year warranty and international support.

Gamma immunity

Lighthouse Worldwide Solutions advanced photodetector technology allowed us to improve the optical signal to noise and lower gamma-ray interference 20 times. This means if your particle counter is reporting counts there are detectable particle counts in your ultra-pure water system.

Count subtraction is not used since we have the lowest false count rate in the industry. The Vertex50 reports the counts as soon as they come in, without waiting for an arbitrary value to be reached before the counter recognizes the particle counts.

Early Detection

With early detection comes the Vertex50s proven clean-up time after an event; the Vertex50 returns to baseline counts within 120 seconds after a particle event.

Want to learn more about where Gamma Immunity and sensitivity meet? Contact your local Lighthouse representative today.

Key Features:

  • Channel sizes: 50nm, 100nm, 150nm, 200nm
  • Four channels of simultaneous count data
  • 100 mL per minute flow rate
  • Built-in 3.5” color touch screen display
  • 316L stainless steel construction
  • Ethernet, RS485 Modbus Serial, 4-20mA
  • NEMA style enclosure
  • Integrated manual flow control
  • Interfaces with existing building automation and facility management systems
