技术细节
| ApexP3 | ApexP5 | |
规格参数 |
||
| 最小探测粒径 | 0.3 μm | 0.5 μm |
| 标准粒径通道 | 0.3, 0.5, μm | 0.5, 5.0 μm |
| 可选4通道 | 0.3, 0.5, 1.0, 5.0 μm | 0.5, 1.0, 5.0, 10.0 μm |
| 可选更换通道 | 0.3, 0.5, 0.7, 1.0, 3.0, 5.0 μm | 0.5, 0.7, 1.0, 3.0, 5.0, 7.0, 10.0 μm |
| 流量 | 1 CFM (28.3 LPM) | |
| 通讯 | Ethernet or Serial | |
| Modbus协议 | TCP or RTU or ASCII | |
| 端口 | Ethernet, RS485 (RJ-45), USB | |
| 显示屏幕 | 5.7 inch color touch screen | |
| 数据存储 | 3000 | |
| 地点数 | 200 | |
| 自动侦测状态 | Yes | |
| 内置Web服务器 | Yes | |
| 报警声音可调 | Yes | |
| 报告 | ISO 14644-1, EU GMP Annex 1, FS-209E | |
| 数据保存和传输 | Designed to meet 21 CFR Part 11 compliance | |
| 语言 | English, Spanish, German, French, Italian, Russian, Simplified Chinese, Japanese, Korean | |
| 尺寸 | 9.00 x 6.69 x 8.46" (22.86 x 16.99 x 21.48 cm) | |
| 重量 | 10.9 lbs (4.76 kg) | |
| 外壳 | 304 Stainless Steel | |
| 电源 | 24 VDC, 5 amp max draw | |
| 电池 | 4 hrs nominal, 3 hrs continuous | |
| 真空泵 | PID Controlled Vacuum Pump | |
| 内置排气过滤器 | Internally filtered to HEPA standard (>99.97% @ 0.3μm) | |
| 采样模式 | Automatic, Manual, Beep, Concentration | |
| 校准 | Designed for ISO 21501-‐4 compliane, annual calibration | |
| 光源 | Laser Diode | |
| 零计数 | <1 count /5 minutes per ISO 21501- 4 | |
| 浓度上限 | 500,000 particles/ft3 (17,150,000/m3) @ 5% coincidence loss suitable for ISO classes 1- 8 cleanrooms | |
| 计数效率 | 50% @ minimum channel size 100% for particles >1.5 X - 2 X first channel particle size | |
可选 |
||
| 软件 | LMS Express, LMS Express RT, LMS Pharma | |
| 打印机 | USB Printer | |
询价
超便携式空气粒子计数器：0.3微米感应度，1.0CFM流量
The ApexP3 Portable Particle Counter can store up to 3,000 records of particle count data from up to 4 particle channels and the configurable database can store up to 50 recipes for sampling and reports.
Self-Diagnostics
The ApexP3 was designed with an internal Self-Diagnostic technology that continuously monitors the health of the laser ensuring reliability of the particle count data. Apex Self-Diagnostics on the laser, flow rate and particle detector ensure that the instrument is operating within specified tolerances.
Secure Data Transfer
The ApexP3 Secure Data Transfer allows all particle count data to be quickly and reliably transferred to a USB flash drive, Computer, Facility Monitoring System or Building Automation System. ApexP3 has a flexible data communication through the integrated RS-485 Modbus and USB flash drive interfaces.
Data Availability
View ApexP3 data on the built in 5.7 inch color touch screen, USB interface, external printer, web server or communicate Modbus/TCP/IP to 3rd party software applications.
Web Server
View real time data on your laptop, tablet or smart device.
Printing
Choose our optional USB Printer to print cleanroom certification pass/fail reports: Federal Standard 209E, ISO 14644-1: 1999 and ISO 14644-1: 2015 and EU GMP Annex 1
Environmental Compatibility
Compatible with all decontamination processes
The ApexP3 uses a 304 Stainless Steel enclosure, sealed inlets, and is compatible with H2O2 Vapor Decontamination.
Key Features
- 0.3 – 10.0 μm Particle Size Range
- 1.0 CFM (28.3 LPM) Flow Rate
- 5.7 inch color touch screen display
- 3,000 records Data Storage
- Self-Diagnostics
- Remote Access via the internal web server
